Parameter:



Material	Nut: Polypropylene Body: PP Clinching-Ring: POM  O-ring: Rubber NBR or EPDM
Color	Gray,Blue or White
thickness	1.2mm-2.5mm
Specifications	DN15-DN200
Working  temperature	for cold water ≤ 60 °C during transfer for hot water delivery time ≤ 95 °C
Working Pressure	PN10
Size:	16mm to 110mm



Features & Application:

 application

Pipe fittings are applied to construction, electrical conduit, agricultural irrigation, industrial sewage and other projects using .



1) Cold and hot water supply systems for civil and industrial constructions, e.g.in residential buildings, hospitals, hotels, school and office buildings, shipbuilding

2) Drinking water systems and food industry pipe works

3) Central air conditioning system

4) Irrigating system for gardens and green houses

5) Public and sport facilities such as swimming pools and stadiums

6) For rainwater utilization systems



Material List:





Part	Material	Color
Body	Polypropylene block copolymer(PP-B) of exceptional mechanical properties even at high temperature.	black
Nut	Polyprolene with dye master of high stability to UV rays and solidity to heat(8 grade according to standard DIN 54004)	blue
Clinching ring	Polyacetal resin(POM)with high mechanical resistance white and hardness	white
Blocking bush	Polypropylene	black
O Ring gasket	Special elastomeric acrylonitrile rubber(NBR) for alimentary use	black
Reinforcing ring	AISI 430(UNI X8Cr17,W.nr 14828)Stainless steel for female threads for 1/2”to 4”	silver



Product Feature:



1)  light weight, convenient handling and corrosion-resistant

2)  chemical stability , fluid resistance

3)  anti-aging, long life, non-toxic

4)  Smooth inner wall ,reducing pressure loss and increasing flow speed

5)  Low noise ,reduced by 40% compared to galvanized steel pipes

6)  Easy and fast installation, making cost minimized

7)  Apply to construction, electrical conduit, agricultural irrigation, industrial sewage.

 Products Picture:



Exploded View:





Working Picture:
